描述
| item | unit | Design value |
| Machine model and name | / | DY1404 wheeled tractor |
| Overall type | / | Wheel type |
| Machine frame type | / | frameless |
| Overall drive type | / | Four-wheel drive |
| Application of the whole machine | / | General purpose |
| Overall dimensions (length × width × height and position) | mm | 4690×2100×2940 (top of cab) |
| Wheelbase or track ground length | mm | 2310 |
| Commonly used wheel gauge (front/rear) or gauge | mm | 1600/1650 |
| Wheel gauge (front/rear) or gauge | mm | 1600, 1650/1605 ~ 1725 |
| Minimum ground clearance and position | mm | 397 (bottom of front axle) |
| The horizontal distance between the front end face of the clutch housing and the axis line of the rear drive shaft | mm | 1310 |
| Transmission gear pair shaft hole center distance | mm | 118 |
| The horizontal distance between the axis line of the drive wheel and the axis line of the guide wheel of the full track tractor | mm | / |
| Minimum service mass | kg | 4760 |
| Standard counterweight (front/rear) | kg | 308/344 |
| Specific ground pressure of track | kPa | / |
| Minimum use ratio mass | kg/kW | 46.21 |
| Gear (forward/backward) | / | 8 + 16 |
| Number of main gear shifts | / | 4 |
| Number of sub shift gears | / | (2+1) times 2 |
| Maximum theoretical design speed | km/h | 33.7 |
| Engine and main clutch connection mode | / | Direct connection |
| Rollover protection (cab or safety frame) model | / | SD1604.45.001 |
| Type of tip guard (cab or safety frame) | / | Simple cab |
| Plant for production of tip protection devices (cab or safety frame) | / | China |
| Engine type | / | YCD4J33T6-140A |
| Engine structure type | / | In-line, water-cooled, four-stroke |
| Engine plant | / | Guangxi Yuchai power Co., LTD |
| Engine intake mode | / | supercharge |
| Engine cylinder count | / | 4 |
| Engine rated power | kW | 103 |
| Net engine power rating | kW | 103 |
| Nominal engine speed | r/min | 2300 |
| Engine cooling mode | / | water-cooling |
| Air filter model | / | 4J |
| Air filter type | / | dry-type |
| Exhaust pipe muffler dimensions (length × width × thickness) | mm | Phi 150 x 840 |
| Exhaust pipe muffler quality | kg | 11 |
| Driver seat model | / | SMT-CS06-1 |
| Driver seat manufacturing plant | / | China |
| Seat belt model | / | FS2001 |
| Seat belt factory | / | China |
| Steering system type | / | Full hydraulic |
| Steering system steering control mechanism | / | Steering wheel |
| Steering system steering mechanism type | / | Front steering |
| Number of driveshains, type of gearbox | / | Number of boxes: 2, mechanical plane composition |
| Main shift position and main shift mode | / | Main transmission position: in the first box, the machine has stage gear |
| Secondary gear shift mode | / | The machine has stage gear |
| Tire type (front/rear) | / | 12.4-24/16.9-34 |
| Number of tires (front/rear) | a | 2 + 2 |
| Track material | / | / |
| Track plate width | mm | / |
| Type of hydraulic suspension system | / | Separate type |
| Suspension type | / | Rear three-point suspension |
| Suspension class | / | The second kind |
| Working device hydraulic oil pump model | / | D4Y |
| Number of hydraulic output groups | / | 3 groups |
| Working device safety valve full open pressure | MPa | 17.5 + / – 0.5 |
| Number of splines of power output shaft | / | 8 |
| Standard speed of power output shaft | r/min | 760/850 |
