AGRIDISOURCE 704-G 70HP 4WD Agricultural Tractor
| Specification | Details |
|---|---|
| Brand | AGRIDISOURCE |
| Model | 704-G |
| Rated Power | 70 HP |
| Engine Model | YN38NDE4 |
| Engine Brand | Kunming Yunnei Power |
| Engine Power | 51.5 kW |
| Engine Type | 4-cylinder, water-cooled, naturally aspirated |
| Emission Standard | China Stage IV |
| Rated Engine Speed | 2300 rpm |
| Drive Type | 4WD |
| Transmission | Mechanical |
| Gears | 8 Forward + 8 Reverse |
| Maximum Theoretical Speed | 30.08 km/h |
| Steering System | Full Hydraulic Steering |
| Tire Size (Front/Rear) | 7.50-16 / 11.4-28 |
| Hydraulic Outputs | 2 |
| Rear Suspension | Three-Point Suspension, Category I |
| PTO Speed | 540 / 720 rpm |
| Wheelbase | 1945 mm |
| Ground Clearance | 310 mm |
| Dimensions (L × W × H) | 3680 × 1550 × 2600 mm |
| Minimum Service Mass | 2210 kg |
| Standard Counterweight (Front/Rear) | 48 / 56 kg |
| Cab Type | Simple Cab |
The AGRIDISOURCE 704-G is a 70HP 4WD agricultural tractor powered by a 51.5 kW Kunming Yunnei YN38NDE4 four-cylinder, water-cooled diesel engine. It features an 8-forward and 8-reverse mechanical transmission, full hydraulic steering, two hydraulic output groups, and a Category I rear three-point suspension system. With 540/720 rpm PTO speeds and 4WD traction, this tractor is suitable for general farm operations and a range of agricultural tasks.
Weifang Diyuan Machinery Technology Co., LTD is a Chinese supplier of agricultural tractors and tractor spare parts. Under the AGRIDISOURCE brand, we provide agricultural machinery solutions for farmers, importers, dealers, and distributors worldwide. Our product range includes 4WD agricultural tractors, agricultural implements, and tractor spare parts.
