90HP 4WD Agricultural Tractor DY904 | China Tractor Manufacturer | AGRIDISOURCE
| Item | Specification |
|—|—|
| Model | DY904 |
| Power | 90 HP / 66.2 kW |
| Tractor Type | Wheeled Tractor |
| Drive Type | Four-Wheel Drive |
| Application | General Purpose |
| Overall Dimensions | 4180 × 1820 × 2725 mm |
| Wheelbase | 2080 mm |
| Wheel Gauge | Front 1420 mm / Rear 1485 mm |
| Minimum Ground Clearance | 385 mm |
| Minimum Service Mass | 2840 kg |
| Standard Counterweight | Front 80 kg / Rear 180 kg |
| Transmission | 12F + 12R |
| Main Gear Shifts | 4 |
| Secondary Gear | 3 × (1+1) |
| Maximum Speed | 29.91 km/h |
| Engine Model | YN4PL090-33CR |
| Engine Manufacturer | Shandong Yunnei Power Co., Ltd. |
| Engine Type | 4-Cylinder, 4-Stroke, Water-Cooled Diesel |
| Intake Mode | Supercharged |
| Rated Power | 66.2 kW |
| Rated Speed | 2300 r/min |
| Steering System | Full Hydraulic Steering |
| Tire Size | Front 9.5-24 / Rear 14.9-30 |
| Hydraulic Pump | Gear Pump CB-F320L |
| Hydraulic Outputs | 2 Groups |
| Hydraulic Safety Valve Pressure | 20 ± 0.5 MPa |
| PTO Spline | 6 or 8 |
| PTO Speed | 540 / 760 r/min |
| Suspension | Rear Three-Point Suspension |
| Suspension Class | Category II |
| Safety Protection | Simple Cab |
| Optional Tires | 8.3-24 / 11.2-32; 9.5-24 / 14.9-30 |
| Optional Safety Protection | Safety Frame |
90HP 4WD Agricultural Tractor DY904
AGRIDISOURCE DY904 is a 90 horsepower four-wheel drive agricultural tractor designed for general farming, field operations and transportation. It is equipped with a YN4PL090-33CR 4-cylinder supercharged diesel engine, 12F+12R mechanical transmission, full hydraulic steering and rear three-point suspension. With 66.2 kW rated power and multiple tire options, the DY904 is suitable for different agricultural applications and implements.
About Weifang Diyuan Machinery Technology Co., Ltd.
Weifang Diyuan Machinery Technology Co., Ltd. is a professional agricultural machinery supplier from China, specializing in agricultural tractors, tractor implements and tractor spare parts.
Located in Weifang, Shandong Province, China, we cooperate with professional tractor manufacturing factories to provide reliable agricultural machinery solutions for farmers, dealers and distributors worldwide.
Our products include different horsepower agricultural tractors, four-wheel drive tractors, agricultural implements and tractor spare parts. We provide tractor supply, configuration selection, spare parts support and export services.
