60HP 4WD Agricultural Tractor DY604 | China Tractor Manufacturer | AGRIDISOURCE
| Item | Specification |
|---|---|
| Model | DY604 Wheeled Tractor |
| Power | 60 HP |
| Tractor Type | Wheeled Tractor |
| Drive Type | Four-wheel Drive |
| Application | General Purpose |
| Overall Dimension | 3550 × 1390 × 2340 mm |
| Wheelbase | 1895 mm |
| Wheel Gauge | 1100/1090 mm |
| Minimum Ground Clearance | 315 mm |
| Minimum Service Mass | 1798 kg |
| Standard Counterweight | Front 48 kg / Rear 80 kg |
| Gear | 8 Forward + 2 Reverse |
| Main Gear Shift | 4 + 1 |
| Secondary Gear Shift | 2 |
| Maximum Speed | 28.89 km/h |
| Engine Model | YN4A065-32CR2 |
| Engine Manufacturer | Shandong Yunnei Power Co., Ltd |
| Engine Type | Vertical Inline Four-cylinder Four-stroke |
| Rated Power | 44.5 kW |
| Rated Speed | 2300 r/min |
| Intake Mode | Supercharged |
| Cooling System | Water Cooling |
| Steering System | Full Hydraulic Steering |
| Tire Size | 7.5-16 / 11.2-28 |
| Tire Quantity | 2 + 2 |
| Hydraulic Pump | CBN-E320 Gear Pump |
| Hydraulic Output | 2 Groups |
| Hydraulic Safety Valve Pressure | 18 ± 0.5 MPa |
| PTO Spline | 8 or 6 |
| PTO Speed | 540/720 rpm |
| Suspension Type | Rear Three-point Suspension |
| Suspension Class | Category I |
| Safety Frame | DY604.41.3 |
| Optional Tire Size | 6.0-16/9.5-24; 6.5-16/11.2-24; 8.3-20/12.4-28 |
60HP 4WD Agricultural Tractor DY604
AGRIDISOURCE DY604 is a 60 horsepower four-wheel drive agricultural tractor designed for general farming, field work and transportation. It features a YN4A065-32CR2 diesel engine, mechanical transmission, full hydraulic steering and rear three-point suspension. The tractor supports multiple tire configurations and PTO speeds, making it suitable for different agricultural applications and implements.
